Vacuum Equipment
350,000 ₫
・Supply valve: An N.O. specification has been added.
Can hold vacuum∗ even when the power goes out or is turned off
Prevents the sudden dropping of workpieces∗
∗ Supposing the supply pressure is being maintained
・An IO-Link compatible pressure switch has been added.
Allows for ejector control with a single communication line
Reading of the device information and parameter batch settings are
possible.
・Compatible with ejector systems and vacuum pump systems
・Energy saving ejector
Air supply is cut-off when vacuum is reached.
Air consumption: 93% reduction (Under SMC’s measurement conditions)
・More efficient ejector: Suction flow increased by 50% (Compared to other
SMC 1-stage ejectors)
・Energy saving efficiency: 93% reduction
・Improved low noise and suction flow by adoption of a high-noise
reduction silencer
- Cung cấp đầy đủ CO/CQ cho tất cả mặt hàng phân phối
- Bảo hành chính hãng, giao hàng toàn quốc
| Ejector series | Nozzle diameter (mm) |
Max. suction flow [L/min(ANR)] |
Air consumption [L/min(ANR)] |
Guidelines for applicable pad (mm) |
Vacuum pump system series |
|---|---|---|---|---|---|
| ZK2□07 | 0.7 | 29 | 24 | 2 to 40 | ZK2□00 |
| ZK2□10 | 1.0 | 44 | 40 | 2 to 50 | ZK2□00 |
| ZK2□12 | 1.2 | 61 | 58 | 2 to 125 | ZK2□00 |
| ZK2□15 | 1.5 | 67 | 90 | 2 to 150 | ZK2□00 |
Features
Energy saving ejector
High-noise Reduction Silencer
Improved low noise and suction flow by adoption of a high-noise reduction silencer
Low noise: 46 dB (A)*
∗ Nozzle size: ø0.7 (Under SMC’s measurement conditions)
Suction flow: Improved by up to approx. 20%
All in One: Piping, wiring, and installation time reduced!!
Wiring variations
Mounting (Options)
Vacuum Unit Variations Single Unit
Vacuum Unit Variations Manifold
IO-Link Compatible
Energy saving is possible due to the vacuum pressure switch with energy saving function and efficient ejectors.
Air consumption: 93% reduction
(Based on SMC’s measurement conditions)
Nguồn bài viết https://www.smcworld.com/webcatalog/en-jp/vacuum-equipment/vacuum-ejectors-vacuum-generators/ZK2_A-E
